New Boards @surfindian

New at Surfindian.

6’0″ polka moo: Geppy #2’s, 6×6(6), gloss and polish. Beak nose, downrail, arc tail

6’7″ HPH speedster: Geppy #2’s, 6×6(6), smoke tint bands top and bottom, gloss and polish. Too sweet.





new, new, new and new!



I’ve got four new boards at Surfindian in beautiful Pacific Beach, San Diego. Stop in and check them out or contact the store for shipping anywhere.

6’1″ HPH speedster quad, cool fall color Mexican blanket resin job, fins 101 bamboo canard quad glass ons, polished gloss

6’7″ HPH speedster, deep aqua tail dip w/ smoke stripe, Geppy keels, polished gloss

7’6″ hillbilly quad, moss green bottom tint, Geppy/Frye quad glass ons, sanded gloss

9’7″ HPH, jailbreak/beetlejuice resin job top and bottom, Geppy keels, polished gloss

Photos soon.

Hullls

displacement or planing?

I see a lot of traffic on the net these days looking for hulls. I’m am by no means an expert on surfboard design, but I am an avid student of design and have researched a fair amount. Here is some of what I’ve learned.

Although the recent fascination with hulls has centered around the Greg Liddle “modified transitional displacement hulls”, any surfboard can be considered a hull. There are displacement hulls, planing hulls and as usually is the case, some variant of the two.

As soon as you put an edge at the tail of your board you have created a planing hull. The very nature of the release provided by that edge, by definition puts that board into planing mode. It the edge were left soft and round, you still have a displacement hull. Now whether it is a good one of either type is another matter.

Have you ever seen the old footage of guys towing behind motor boats on their logs? As soon as they get going, the tail end of the board starts submarining and they can literally walk to the nose and go. This demonstrates a the principle of displacement hull theory. A displacement hull has a theoretical hull speed, above which the water actually sucks the hull deeper into the water (I’m simplifying here). Take a sailboat or any other displacement hull and tow it. At anything above the theoretical hull speed, the boat begins to submarine, actually being pulled deeper into the water. Old, soft edged boards are the same, as are any true displacement hulls being produced today. As soon as you put an edge at the tail, you release the water and the board begins to plane. The modern surfboard, most “hulls” included, balance these principles to achieve the desired effect or feel.

Now I’m sure I’ll get some flak for this, but displacement hulls, by their very nature, are not as fast as planing hulls. They may “feel” faster in a section, but without the release, they are constantly dragging more than a sharp edged board would. Now this is not a bad thing. The feeling of a well balance hull is one of the great pleasures of surfing that most people fail to credit. Surfing one well takes a different approach, especially if you are stepping off a thruster. Single fin riders tend to have an easier time.

Another thing I’ll take flak for, and I’m saying it anyway, Greg Liddle did not invent the displacement hull surfboard. He refined it to an amazing degree, made it work in a short package, championing it when it was completely against the trends of the time, but have you ever seen a Weber Foil? Have you ever really looked at almost any board before the mid sixties? All displacement hulls, although arguably not “modified transitional displacement hulls”, whatever that means. Please don’t take this as me dissing Greg Liddle. On the contrary, I think his boards are brilliant and have been a huge design influence for me. It’s just I get a little frustrated when I here people talk about hull this and hull that, without any understanding of what a hull is.

Thanks



SURFINDIAN!

Chris and his crew at Surfindian have expanded and are opening the old Star Surfing Co. space as a new, high end board shop. I have the pleasure and honor of being in the lineup there. Other shapers/labels you may have heard of include, Skip Frye, Donald Takayama, Pauk Strauch Jr., Tyler, Hydrodynamica (Richard Kenvin/Carl Ekstrom), and Michael Miller. That is one intimidating lineup, but I am stoked out of my mind to be included. Look for a Surfindian/mast surfboards collaboration in the future.
